Heavy type welded mesh can be used to build a premier finished concrete wall strengthened with layer of galvanized welded wire mesh panels. Light type meshes welded with small wire diameter can be used for poultry houses, egg baskets, runway enclosures, draining racks, porch guards, rat-proofing, safety guards on machinery and shelves, etc.
Welded Wire Mesh for Building Materials:
Welded Wire Mesh is the traditional metal materials for building constructions. It is made of superior quality welded mesh, with flat even surface, firm structure, be used extensively in building, construction, food, agriculture and fencing.
Forms: Arch welded wire building materials are mainly delivered and formed in the structure of Truss mesh, Ladder Mesh, Stucco Netting, Welded Ribbed Reinforcement Panels, slab mesh reinforcing, brick masonry wall reinforcing panels and welded pile cages or spiral pipes. Details please refer to the listing below. |
| |
| Welded Wire Mesh |
|
| |
|
|
|
|
|
|
 |
|
Electro-welded Mesh |
| Welded mesh, in Stainless steel or carbon steel, pre zinc plated or electro galvanized. For a wide engineering and processing uses. |
|
|
|
|
|
|
|
|
| |
|
|
 |
|
Metal Mesh |
| Low Carbon Steel Welded Mesh, Hot Dipped Zinc Galvanized. PVC or epoxy coating can be added. |
|
|
|
|
|
|
| |
| |
|
|
|
| |
| Welded Wire Mesh Technical Details: |
|
Material: Low carbon steel wire, stainless steel wire
Varieties of Finishes:
1 - Electro galvanized mesh(welded before galvanized, welded after galvanized)
2 - Hot-dipped galvanized mesh(welded before galvanized, welded after galvanized)
3 - PVC coated mesh(wire dia. of PVC is about 0.4mm)
Specification of the welded wire mesh for building materials:
| Specification List of Welded Wire Mesh: |
| Opening |
Wire Diameter<BWG> |
| In inch |
In metric unit(mm) |
| 1/4" x 1/4" |
6.4mm x 6.4mm |
22,23,24 |
| 3/8" x 3/8" |
10.6mm x 10.6mm |
19,20,21,22 |
| 1/2" x 1/2" |
12.7mm x 12.7mm |
16,17,18,19,20,21,22,23 |
| 5/8" x 5/8" |
16mm x 16mm |
18,19,20,21, |
| 3/4" x 3/4" |
19.1mm x 19.1mm |
16,17,18,19,20,21 |
| 1" x 1/2" |
25.4mm x 12.7mm |
16,17,18,19,20,21 |
| 1-1/2" x 1-1/2" |
38mm x 38mm |
14,15,16,17,18,19 |
| 1" x 2" |
25.4mm x 50.8mm |
14,15,16 |
| 2" x 2" |
50.8mm x 50.8mm |
12,13,14,15,16 |
Technical Note:
1.Standard roll length: 30m; width: 0.5m to 1.8m
2.Special sizes available at request.
3.Packing: in waterproof paper in rolls.
Custom packing available at request.
|
| |
|
| |
