General Use: Stainless steel wire mesh, with its excellent resistance against acid, alkali, heat and corrosion, find extensive uses in processing of oils, chemicals, food, pharmaceuticals, also sorting and screening of solid, liquid and gas in mine, metallurgy, airspace, machine making, etc.
Specification List of Stainless Steel Wire Mesh
Mesh/Inch
Wire Gauge(SWG)
Aperture in mm
3mesh x 3mesh
14
6.27
4mesh x 4mesh
16
4.27
5mesh x 5mesh
18
3.86
6mesh x 6mesh
18
3.04
8mesh x 8mesh
20
2.26
10mesh x 10mesh
20
1.63
20mesh x 20mesh
30
0.95
30mesh x 30mesh
34
0.61
40mesh x 40mesh
36
0.44
50mesh x 50mesh
38
0.36
60mesh x 60mesh
40
0.30
80mesh x 80mesh
42
0.21
100mesh x 100mesh
44
0.172
120mesh x 120mesh
44
0.13
150mesh x 150mesh
46
0.108
160mesh x 160mesh
46
0.097
180mesh x 180mesh
47
0.09
200mesh x 200mesh
47
0.077
250mesh x 250mesh
48
0.061
280mesh x 280mesh
49
0.060
300mesh x 300mesh
49
0.054
350mesh x 350mesh
49
0.042
400mesh x 400mesh
49
0.0385
500mesh x 500mesh
50
0.0273
Roll width: 2'-8'
Chemical composition of stainless steel wire:
AISI
Grade
Chemical Composition(%)
C
Si
Mn
P
S
Ni
Cr
Mo
304
=0.08
=1.00
=2.00
=0.045
=0.030
8.00~10.50
18.00~20.00
-
304H
>0.08
=1.00
=2.00
=0.045
=0.030
8.00~10.50
18.00~20.00
-
304L
=0.030
=1.00
=2.00
=0.045
=0.030
9.00~13.50
18.00~20.00
-
316
=0.045
=1.00
=2.00
=0.045
=0.030
10.00~14.00
10.00~18.00
2.00~3.00
316L
=0.030
=1.00
=2.00
=0.045
=0.030
12.00~15.00
16.00~18.00
2.00~3.00
430
=0.12
=0.75
=1.00
=0.040
=0.030
=0.60
16.00~18.00
-
430A
=0.06
=0.50
=0.50
=0.030
=0.50
=0.25
14.00~17.00
-
Sizes of Stainless Steel Wire:
Wire Diameter(mm)
Tolerance(mm)
Max. Deviation Tolerance(mm)
0.020-0.049
+0.002
-0.001
0.001
0.050-0.074
0.002
0.002
0.075-0.089
0.002
0.002
0.090-0.109
+0.003
-0.002
0.002
0.110-0.169
0.003
0.003
0.170-0.184
0.004
0.004
0.185-0.199
0.004
0.004
0.200-0.299
0.005
0.005
0.300-0.310
0.006
0.006
0.320-0.499
0.006
0.006
We can supply other specifications according to the customer's requirement.
